Pressure gauge supporting OEM services. Any design can be customized according to specific customer requirements.
| Model |
Scale Range (KPa) |
Accuracy Grades |
| Positive Pressure |
Negative Pressure |
Positive & Negative |
| YE-60 |
0~2.5 |
-2.5~0 |
-2 ~+2 |
2.5 |
| 0~4 |
-4~0 |
-3~+3 |
| 0~6 |
-6~0 |
-5~+5 |
| 0~10 |
-10~0 |
-8~+8 |
| 0~16 |
-16~0 |
-12~+12 |
| 0~25 |
-25~0 |
-20~+20 |
| 0~40 |
-40~0 |
- |
● DIAPHRAGM MATERIAL: QSn6.5-0.1
● CONNECTOR MATERIAL: HPb59-1
● WORKING POSITION: Vertical installation
● TEMPERATURE RANGE: -25~55°C
● RELATIVE HUMIDITY: ≤80%
● TEMPERATURE EFFECT: Deviates 20 ± 5 °C, error not more than 0.4% / 10 °C.
?
Frequently Asked Questions
What is the accuracy grade of the YE-60 pressure gauge?
The YE-60 series capsule pressure gauge features an accuracy grade of 2.5, ensuring reliable readings for medium-pressure applications.
What materials are used for the gauge components?
The gauge is constructed with a high-quality stainless steel case, a QSn6.5-0.1 diaphragm, and a durable HPb59-1 brass joint/connector.
Does this product support customization?
Yes, we provide full OEM support. Designs can be customized according to specific client requirements, including scale ranges and branding.
What are the recommended operating environmental conditions?
The gauge operates optimally in temperatures between -25°C and 55°C, with a relative humidity of ≤80% in air free from corrosive gases.
What thread sizes are available for connection?
The standard thread options include 1/8" and 1/4" sizes, compatible with PT, NPT, and G thread standards.
How should the pressure gauge be installed for best results?
The instrument is designed for vertical installation to maintain accuracy and prevent additional mechanical stress.
