⚙️ Basic Specifications
Charge Method
Quick Charge
Output Voltage
150-1000V DC
Communications
OCPP 1.6 JSON
Connectivity
Ethernet / 4G / WiFi
Display
7” TFT Color Touch Display
Environment Temp
-40 ~ +60 ℃
📊 Technical Parameters
| Parameter Item |
Technical Details |
| Input Voltage | 400V ± 15% AC |
| Frequency | 50/60 Hz |
| Output Interface | Double CCS2 Connectors |
| Output Voltage Range | 150 - 1000V DC |
| Maximum Efficiency | ≥ 95% |
| THD (Harmonic Distortion) | ≤ 5% @ 50%~100% Load |
| Power Factor | ≥ 0.99 |
| Cooling System | Forced Air Cooling |
| Safety Protection | O-PEN Protection, Over/Under Voltage, Overload, Short Circuit, Leakage |
| Noise Level | < 65 dB |
| Impact Protection | IK08 |
🌟 Key Features
-
🛡️
Rugged Durability: IP55 rated protection and IK08 impact resistance, designed for harsh outdoor environments (-40°C to +60°C).
-
⚡
Multi-Standard Support: Compatible with GB/T and CCS2 charging standards to suit various electric vehicle models.
-
📱
Smart Interface: Features a 7-inch TFT color touch display supporting RFID, App-based control, and POS payment integration.
-
☁️
Cloud Management: Full support for OCPP 1.6J protocol via 4G, WiFi, or Ethernet for remote monitoring and commercial billing.
📦 Packaging & Delivery
Package Size
135.0cm * 160.0cm * 200.0cm
Lead Time
15 Days (1 Unit); Negotiable for bulk
Transport Type
Standard Export Pallet or Wooden Box
❓ Frequently Asked Questions
Q1: What is the typical lead time for an order?
For a single unit, the lead time is approximately 15 days. For larger quantities, the schedule can be negotiated based on production capacity.
Q2: Which certifications do your EV chargers hold?
Our charging stations are fully certified with CE and TUV standards, ensuring safety and compliance for international markets.
Q3: What is the warranty period for the charging equipment?
We provide a comprehensive 12-month warranty on our DC integrated charging stations.
Q4: Do you support OEM or ODM customization?
Yes, we have extensive experience in OEM and ODM services since 2012, allowing for customized branding, colors, and technical specifications.
Q5: What are your accepted payment terms?
We typically accept T/T payments with a 30% deposit upfront and the remaining balance due before shipment.
Q6: Which charging protocols and connectivity options are available?
The chargers support CCS2, GB/T, and J1772 standards. Connectivity includes RFID, Wi-Fi, App integration, and OCPP 1.6j protocol support.
