K064 Front-Mounted Dual-Output DC Power Unit High-Power Charging System for Commercial Electric Vehicles
K064 Front-Mounted Dual-Output DC Power Unit High-Power Charging System for Commercial Electric Vehicles
K064 Front-Mounted Dual-Output DC Power Unit High-Power Charging System for Commercial Electric Vehicles
K064 Front-Mounted Dual-Output DC Power Unit High-Power Charging System for Commercial Electric Vehicles
K064 Front-Mounted Dual-Output DC Power Unit High-Power Charging System for Commercial Electric Vehicles
1 / 5
K064 Front-Mounted Dual-Output DC Power Unit High-Power Charging System for Commercial Electric Vehicles
K064 Front-Mounted Dual-Output DC Power Unit High-Power Charging System for Commercial Electric Vehicles
K064 Front-Mounted Dual-Output DC Power Unit High-Power Charging System for Commercial Electric Vehicles
K064 Front-Mounted Dual-Output DC Power Unit High-Power Charging System for Commercial Electric Vehicles
K064 Front-Mounted Dual-Output DC Power Unit High-Power Charging System for Commercial Electric Vehicles

K064 Front-Mounted Dual-Output DC Power Unit High-Power Charging System for Commercial Electric Vehicles

Still deciding? Get samples of $ !
Order Sample
Send Inquiry

Product Description

Product Overview

Model: K064 DC Charging with Double Front Guns
Location: Public Use
Start Mode: Credit Card, RFID, Scanning Codes
Power Output: DC 60-160kw
Protection Level: IP54
Type: Fast EV Charging Station
Certification: CCC, CE, ISO, TUV
Warranty: 24 Months

Product Gallery

DC Power Unit Front View
DC Power Unit Side View
Charging System Details
Commercial EV Charging

Technical Specifications

Power OutputDC 60-160KW
Input VoltageAC 380V±20% 3 Phase
Rated Output VoltageDC 150-1000V
Frequency50-60Hz
ProtocolOCPP 1.6J
HMI7-Inch touch screen
Cable Length5m
Charging Method4G/Ethernet/RFID
Connector TypeCCS1 / CCS2 / CHADEMO / GBT
ProtectionIP54
Temperature Range-30°C to +60°C
Product Size700 x 440 x 1650 mm
Net Weight230 KG

Factory & Production

We are an intelligent EV charging station manufacturing technology center demonstration enterprise. Our facility is recognized as a Municipal Enterprise Technology Research and Development Center with CE, ISO, and IP54 certifications.

Our product range covers 7kw, 11kw, 20kw, 30kw, 40kw, 60kw, 80kw, 120kw, 160KW, 240kw, 320KW, up to 360KW. We provide comprehensive OEM and ODM services with over 5 years of professional experience in the global market.

Production Line
Quality Control
Testing Area

Frequently Asked Questions

What is your packaging term?
Generally, the products are fixed and transported with cardboard shells and wooden stakes to ensure maximum protection during transit.
What are the available payment terms?
We accept various payment methods including T/T and L/C at sight. Please contact our sales team for specific details.
What is the delivery term and method?
We arrange sea freight, air freight, or international express based on customer requirements and the destination.
Is the charging station compatible with all electric vehicles?
Yes, our stations support multiple connector types including CCS1, CCS2, CHADEMO, and GBT, making them compatible with most commercial electric vehicles.
What is the protection level for outdoor use?
The charging station is rated IP54, providing excellent protection against dust and water, suitable for outdoor public use.
Do you offer a warranty on these units?
Yes, we provide a standard 24-month (2 years) warranty and dedicated after-sales service for all our charging units.
