Supports On-grid (Zero Export, Load First, Peak Shaving) and Off-grid modes with optional generator connection.
Status monitoring, insulation detection, dynamic balancing, and comprehensive protection alarms.
Wide DC input range, short power conversion time, and suitable for indoor/outdoor installation.
Integrated Fire Protection and advanced Air Conditioning systems for thermal management.
| Item | Description | Qty | Remarks |
|---|---|---|---|
| PV Solar Panel | HT560M-72H | 960 | Total 537.6KW System |
| Battery Module | 280Ah Lithium | 150 | 51.2V 280AH (14.3kWh per module) |
| Combiner Box | 1500V-1500A | 1 | Multi-rack combination |
| Controller | 1500V 300A | 15 | High Voltage Control |
| PCS500 | Inverter | 1 | 250kW battery inverter |
| 20FT Container | IP54 Enclosure | 1 | Includes HVAC, Fire-fighting, Lighting |
Model: HT560M-72 | Peak Power: 560Wp
Open Circuit voltage: 49.84v | Short Circuit Current: 14.14A
Dimensions: 2279*1134*35mm | Weight: 28kg
Range: 100-1000KW. Can be used alone or with solar chargers. Features flexible configuration, programmable modes, and touchscreen LCD.
1000V level DC to DC controller. Modular design with up to 5 MPPTs. Parallelable units for large scale projects.
Designed for seamless transfer between on-grid and off-grid modes automatically when paired with battery and PV inverters.
