Portable Type 2 Type 1 Gbt Wallbox RFID/4G/CE 22kw/7kw/11kw Wall-Mount Home Use Charging Station Electric Car AC EV Charger for Byd

1 / 5

Portable Type 2 Type 1 Gbt Wallbox RFID/4G/CE 22kw/7kw/11kw Wall-Mount Home Use Charging Station Electric Car AC EV Charger for Byd

Still deciding? Get samples of $ !

Order Sample

Send Inquiry

Product Description

⚡ Basic Info.

Model NO.

SNEV-220/7-F-1-A1

Interfaces

One Pile with One Charge

Location

Public Use

Installation

Wall Mounted

Charge Method

Normal Charge

Output Power

7/11/22kw

Rated Current

16/32A

IP Grade

IP65

Output Voltage

220/380V

Display Size

4.3 inches

Communication

4G, Ethernet

Operating Temp

-20℃~+55℃

📦 Packaging & Delivery

Package Size

18.00cm * 27.00cm * 40.00cm

Gross Weight

4.500kg

📋 Specification

Item	7KW AC EV Charger	11KW AC EV Charger	22KW AC EV Charger
Model Number	SNEV-220/7-F-1-A1	SNEV-380/11-F-1-A1	SNEV-380/22-F-1-A1
Product Size	25080350mm
Input Voltage	220VAC	380-400VAC	380-400VAC
Output Current	32A	16A	32A
IP Rating	IP65
Start-up Modes	RFID card, Scan code, VIN code, Password
Connectivity	4G, Ethernet, Bluetooth
LCD Display	4.3 Inches color screen
Protection	Under/Over Voltage, Short Circuit, Over Current, Lightning, Emergency Stop

🖼️ Product Description

❓ Frequently Asked Questions

1. What is OCPP?

OCPP is abbreviated for open charging point protocol, it is a kind of network protocol. You can connected to our management system in PC via it, and then manage the EV charger and online cards. Also, you could position the EV charger via OCPP.

2. If I get charger with 2 guns, can it charge 2 cars simultaneously?

Yes, for example, if you get a 120kw DC charger with 2 guns, each gun output power will be 60kw, when 2 cars are recharged the power will distributed automatically. If just one car is recharged, it can reach a maximum of 120kw output.

3. What brand name of cars can be recharged?

No matter what brand name, it depends on the connectors of the EV. Different countries use different standards of connectors (Type 1, Type 2, GB/T, NACS).

4. Do you test all your goods before delivery?

Yes, we perform 100% testing on all products before delivery to ensure quality and safety.

5. How about after-sales support?

We provide lifetime technical support, and our engineers provide 24-hour online technical assistance to resolve any issues.

6. What are your terms of delivery?

Our standard delivery terms include FOB, CFR, and CIF.
